With its modern look and features, this RX-4 speedometer is the perfect plug and play meter for many Yamaha bikes including the MT-07/MT-09 or the XSR 700 / XSR900.



Featuring speed, odometer, tripmeter, hour meter, voltage, clock and stopwatch as well as 6 indicator lights, this meter will give you all information you need. You will need an additional bracket to make it fit in the original location for the MT-09 / XRS 700 / XRS 900.

With its modern look and features, this RX-4 speedometer is the perfect plug and play meter for many Yamaha bikes including the MT-07/MT-09 or the XSR 700 / XSR900.



Featuring speed, odometer, tripmeter, hour meter, voltage, clock and stopwatch as well as 6 indicator lights, this meter will give you all information you need. You will need an additional bracket to make it fit in the original location for the MT-09 / XRS 700 / XRS 900.

• Ambient air temperature
  R: 14 ~ 212 °F (‑10 ~ 100 °C)| U: 1 °F (°C)
• Ambient air temp. warning
  D: LO < 14 °F (-10 °C); HI > 212 °F (100 °C ;
  the numbers will turn red and blink
• Coolant temperature
  R: 32 ~ 482 °F (0 ~ 250 °C) | U: 1 °F (°C
• Coolant temperature warning
  D: LO < 102 °F (39 °C); HI > 234 °F (117 °C ;
  the numbers will turn red and blink
• Max. coolant temp. record
  R: 32 ~ 482 °F (0 ~ 250 °C) | U: 1 °F (°C)
• Fuel meter
  R: 6 levels | U: 1 level = 16.6 %
• Low fuel warning
  R: Fuel level ≤ 1 segment the warning signal will blink.
• Current fuel consumption
  R: 0 ~ 99.9 MPG (2.5 ~ 99.9 L/100 km)
  U: 0.1 MPG (0.1 l/100 km)
• Average fuel consumption
  R: 0 ~ 99.9 MPG (2.5 ~ 99.9 L/100 km)
  U: 0.1 MPG (0.1 L/100 km)
• Clock
  R: 12 H or 24 H format
• Riding time
  R: 0 ~ 999.9 H | U: 0.1 H
• Riding time 1, 2
  R: 0 ~ 999.9 H | U: 0.1 H
• Volt meter
  R: DC 8.0 ~ 18.0 V | U: DC 0.1 V
• Low voltage warning
  R: DC 8.0 ~ 13.0 V | U: DC 0.1 V
  D: LO ≤ value, numbers will turn red and blink.
• High voltage warning
  R: DC 13.1 ~ 18.0 V | U: DC 0.1 V
  D: HI ≥ value, numbers will turn red and blink.
• Target speed
  R: 0 ~ 225 MPH (0 ~ 360 km/h)
• Target distance
  R: 1/32 ~ 30/32 mile (50 ~ 1,500 m)
  U: 1/32 mile (50 m)
• Top speed
  D: • Speed : 0 ~ 225 MPH (0 ~ 360 km/h)
  • Distance : 0 ~ 999 m (0~3,280 feet)
  • RPM: 0 ~ value at top speed
  • Time : 0 ~9 : 59”99

• Push info
  • D:
    • Name 4 letters / “…” if > 15 letters
    • Content 17 letters / “…” if > 17 letters
  • Operating system:
    • iOS : supported
    • Android : not supported

• Driving mode
  R: Standard, A, B

• TCS display
  R: 1, 2, Off

• ECO indicator
  R: display, no display

• Backlight color
  R: blue, green, orange, white

• Indicator lights
  ABS / Left turn signal / Check Engine / QS (Quick switch) / TCS (Traction control signal) / Neutral / Coolant temp warning / RPM shift light / IMMO anti-theft / Low fuel warning / High beam / Right turn signal / Motor oil (maintenance) /

• Effective temperature range
  -4 ~ 185 °F (‑20 ~ 85 °C)

• Storage temperature range
  -22 ~ 194 °F (‑30 ~ 90 °C)

• Operating Voltage
  DC 12V
