KOSO BA064902 hd-03 8 Color Led 4 Piece Gauge kit 14-23 Fl Touring
Following the positive reviews we received from Harley enthusiasts, we decided to release the updated bagger meter kit for 2014 to 2023 touring models. This plug & play kit from Koso is now available to replace the stock meters without any hassle! There is no need to drill holes or to rewire the meters, they will fit directly in the OEM dash and connectors. This kit features an 8 color changeable LCD display for a custom look to fit your motorcycle. The HD‑03 kit includes a multifunction speedometer, tachometer, oil temperature meter and a fuel level meter. If you’re looking to enhance the look of your Harley, Koso has the plug & play solution for you!
Specifications
(R= Range U=Unit)
- Tachometer
R: 0 ~ 9,990 RPM | U: 10 RPM - RPM Shift‑light
R: 2,000 ~ 8,000 RPM
Warning lights on > value - Maximum RPM
R: 0 ~ 9,990 RPM | U: 100 RPM - Speedometer
R: 0 ~ 199 MPH (0 ~ 299 km/h)
U: 1 MPH or km/h (alternative) - Overspeed warning
R: 19 ~ 199 MPH (30 ~ 299 km/h)
Warning lights on ≥ value - Maximum speed record
R: 0 ~ 199 MPH (0 ~ 299 km/h) - Odometer
R: 0 ~ 999,999 miles (km) | U: 1 mile (km)
- Tripmeter A/B
R: 0 ~ 9,999.9 miles (km) | U: 0.1 mile (km) - Mileage maintenance
R : Off / 300 ~ 10,000 miles
(500 ~ 16,000 km) ~ -999 miles
U : 100 miles (km) - Engine temperature
R: -40 ~ 572 °F (-40 ~ 400 °C) | - Fuel meter
R: 0 ~ 100 % - Fuel warning setting
- 1-HD Standard
Flashing LCD when > 211 Ω
Off LCD when < 187 Ω - 2-HD Customize
Flashing LCD when < 20%
Off LCD when > 30%
- 1-HD Standard
- Fuel tank volume
OFF / 1 ~ 9.9 US gallons - Average fuel consumption
OFF / MPG (US spec) / MPG (UK spec) L/ 100 km / km/L
-
Remaining mileage
LO RNG displayed when< 10 miles (16 km)
U: 1 mile (km) -
Oil temperature meter
R: 32 ~ 248 °F (0 ~ 400 °C) | U: 1 °F or °C (alt) -
Max. oil temperature record
R: 32 ~ 248 °F (0 ~ 400 °C) -
Clock
R: 12 H or 24 H format -
Volt meter
R: DC 8 ~ 18 V -
Digits brightness
R: 1/5 (darkest) ~ 5/5 (brightest)
- Indicator lights
Turn signal / Water temp / Oil pressure / Photometric sensing / Warning light/ Check engine / High Beam / Fog light / Volt / Traction control / Cruise / ABS / Rain mode / Vehicle hold control / Fuel level / Low tire pressure / Security light - Gear indicator
OFF, N, P, R, 1, 2, 3, 4, 5, 6 - Effective temperature range
14 ~ 140 °F (‑10 ~ 60 °C) - Effective voltage
DC 12 V - Backlight color
Setting range: white, yellow, orange, red, purple, blue, light blue, green - Does not fit CVO models
