CSF 92-00 Honda Civic w/K-Swap V3 Radiator - Black Finish - 2850KB

MSRP: $525.00

$499.00

(You save $26.00 )

(No reviews yet) Write a Review

Manufacturer Part Number:

2850KB

Availability:

Usually ships in 1-4 business days

Turn 14 Item ID:

521471

Turn 14 Part Number:

csf2850KB

Turn 14 Source Category:

Cooling > Radiators

Turn 14 Source Inventory:

Turn 14 Batch Plan SHA256:

81746F781373A79178CD60D5177CE078715C1FC321C56E4816EA41359BADC013

Turn 14 Sealed Image SHA256:

7683BB675178EC06EF02F82E2F3A4EACDDC5722E0EE7180955780A936F1BC382

Turn 14 VCDB Vehicle IDs 1:

14334,14338,14344,14322,14326,14332,14310,14314,14320,14298,14300,14308,14381,14382,14374,14375,14368,14360,14350,22061,22060,22059,13837,13828,13818,13810,13804,13849,13846,13840,13834,14302,14306,14312,14316,14324,14328,14336,14340,14346,14348

Turn 14 VCDB Vehicle IDs 2:

14352,14354,14356,14358,14362,14364,14366,14367,14369,14370,14371,14372,14373,14376,14377,14378,70545,14379,14380,14383,14384,14386,14342,14318,14330,14304

Product Type:

Radiators

Description
Warranty Information

CSF has over 5 decades of experience manufacturing radiators. So when it comes to keeping your engine cool and your K-Swapped Civic/Integra running at its best, a CSF High-Performance All-Aluminum Radiator is the obvious choice. Designed to perform on the street or at the track, a performance radiator is a must-have for both high horsepower builds as well as race vehicles which need added cooling performance in motorsports environments. This radiator features a 2-Row core with CSF's exclusive B-Tube Technology: Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in the shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (with better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded. The design (inlet in the middle of the tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes - producing the efficiency of two smaller tubes vs. one large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow". CSF also uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab.

Construction: K-Swap 92-00 Honda Civic / 94-01 Acura Integra All-Aluminum Radiator - Black

Features

"Drop-in Fit" Requiring No Modifications to Install - Accepts All Attaching OEM Components Including "Quick Connect" Hoses, AC Condenser, Mounting Brackets and Fan Shroud
Core Features an Ultra-Efficient Fin with 6.5mm Fin Height and Multi-Louvered Design for Maximum Surface Area Contact
2-Row 42mm Core (Dual Core) Featuring CSF's Exclusive B-Tube Technology
CNC Machined Brackets and Fittings for Superb Fit and Durability
CNC Machined "Quick-Connect" Inlet/Outlet Connections
Black Finish for High-End Stealth Look
All-Aluminum Race Style Drain Plug
