AEM 8 Channel K-Type Thermocouple EGT CAN Module - 30-2224

MSRP: $584.95

$519.95

(You save $65.00 )

(No reviews yet) Write a Review

Manufacturer Part Number:

30-2224

Availability:

Usually ships in 1-4 business days

Turn 14 Item ID:

180564

Turn 14 Part Number:

aem30-2224

Turn 14 Source Category:

Data Acquisition > Data Acquisition

Turn 14 Source Inventory:

Turn 14 Batch Plan SHA256:

A77D313B94C409F9419678A2F0B011BDFC83E63DD4F518FC91D4A85E282C7281

Turn 14 Sealed Image SHA256:

CF95806AAAD48D6BEFCB28C3E28EE3059180FEBCF70975361BA4698C40CF000A

Product Type:

Data Acquisition

AEM Channel K-Type Thermocouple EGT/Temperature Sensor Module

Construction: 8-Chan K-Type Thermocouple EGT/Temperature Sensor Module w/ CANbus connectivity

Pre-configured AEMnet CAN bus for plug & play connection to CD Digital Dashes, Infinity ECUs, and AQ-1 (not compatible with Series 2 ECU at this time)
Outputs all channels via configurable CAN bus via one-plug connection (DTM-style Connection Cables sold separately in various lengths)
Includes 8-Channel K-Type EGT CAN Module, 4-Pin DTM-style Connector Plug, instructions and Velcro for in-vehicle mounting
Includes 8 K-type thermocouple inputs to accept common K-type thermocouple sensors (sensors sold separately)
Daisy-chain two modules together for up to 16 temp inputs through a single plug!
Cold junction compensated for lab-grade accuracy (+/- 0.15% full scale)
Measures temperatures from -200 to 1372 degC (-328 to 2501 degF)
Temperature resolution 0.1 degC (0.18 degF)
Uses common miniature thermocouple sockets
Integrated open circuit/fault detection
